This IP camera offers a compression standard that is inter-changeable between the MJPEG and MPEG4, which ensures highest flexibility and allows a system to be optimised depending upon image quality or bandwidth.

Used in-, outdoor, day or night, the high performance CCD sensor enables very high light sensitivity to deliver outstanding images and as the camera supports MPEG4 as well as the international standard RTSP (Real Time Streaming Protocol), video streams can be replayed using standard PC video players such as, Quick Time or VLC. This ensures that the camera can be easily integrated into both new and existing applications.

Siemens hybrid technology also means that the camera can be transferred from a standard BNC connection present in traditional CCTV systems to a digital format (i.e. swapped from coaxial to Ethernet transmission) in order to remain future-proof.

This IP camera offers a compression standard that is inter-changeable between the MJPEG and MPEG4, which ensures highest flexibility and allows a system to be optimised depending upon image quality or bandwidth.

Used in-, outdoor, day or night, the high performance CCD sensor enables very high light sensitivity to deliver outstanding images and as the camera supports MPEG4 as well as the international standard RTSP (Real Time Streaming Protocol), video streams can be replayed using standard PC video players such as, Quick Time or VLC. This ensures that the camera can be easily integrated into both new and existing applications.

Siemens hybrid technology also means that the camera can be transferred from a standard BNC connection present in traditional CCTV systems to a digital format (i.e. swapped from coaxial to Ethernet transmission) in order to remain future-proof.

High resolution day-night camera with infra red sensitivity, advanced digital signal processing techniques to provide crisp, high resolution, aperture corrected, low-smear images, 24 hours a day. Advanced features include: 49-zone programmable back-light compensation, wide dynamic, peak-white inversion and adjustable electronic shutter, ensuring the best images all of the time. The camera includes a built-in ID system for addressing (via RS485) and setup is via on-screen display menu, or via remote setup software. An alarm input triggers up to 4 digital images, stored in the camera and accessible remotely. Supplied with setup software.

CCWC1335 is a high resolution DSP day-night camera with extended 128x dynamic range. Using the latest CCD technology and advanced SONY SS2-DSP signal processing techniques to provide crisp, aperture corrected images, the CCWC1335 camera can be used in a wide variety of applications where image quality is paramount.

Day-Night with Extended Dynamic Range
The camera can compensate for back-light pictures that have areas with differing levels of light using extended dynamic function. With this feature, both under and overexposed picture segments can be optimally displayed. The switch-over from colour to monochrome can be performed automatically depending on ambient light conditions or by external signal using the switch-input of the camera.

Easy Setup
All camera adjustments are performed via a simple to use OSD. Navigation buttons are located behind a discrete side panel. Improved back-focus setup mechanism and function provide easy camera-installation without additional tools such as ND-filters.

Privacy Zones
The camera supports 8 programmable privacy–zones that mask out sensitive picture contents. The masked areas will be displayed blackened.

CCBS1337 is a 540 TVL super high resolution DSP day-night camera using the latest CCD and advanced 10 bit DSP signal processing techniques to provide crisp, aperture corrected images for surveillance applications requiring detailed images.

Day-Night
CCBS1337 is equipped with a mechanical IR-filter that provides good picture quality 24-hours a day in colour and monochrome mode. The switch-over from colour to monochrome can be performed automatically depending on ambient light conditions or by external signal using the switch-input of the camera.

Easy Setup
All camera adjustments are performed via an easy to use OSD. Navigation buttons are located behind a discreet side panel. Improved back-focus setup mechanism and “wizard-function” provide easy camera-installation without additional tools such as day-night filters.

Privacy Zones
The camera supports 8 programmable privacy–zones that mask out sensitive picture contents.. The masked areas will be displayed blackened.

CCBS1345 is a 480 / 540 TVL high resolution day-night camera which provides crisp, aperture corrected images for surveillance applications requiring detailed images.

Day-night CCBS1345 is equipped with a mechanical IR filter that provides good picture quality 24-hours a day in colour and monochrome mode.
The switch-over from colour to monochrome can be performed automatically depending on ambient light conditions (3 levels selectable) or by an external signal using the switch input of the camera.

Twisted Pair Video Output
The additional twisted pair video output enables the transmission of the video signal over 1200 m via simple twisted pair cabling such as telephone cable in conjunction with a suitable receiver such as TP-RXMOD2 or TP-RXI1.

Easy Setup
All camera adjustments are performed via DIP switch. The settings provide powerful functionality such as selection of back-light compensation, automatic exposure shutter for usage of manual and auto-iris lenses,
line-lock function and sharpness selection. DIP switches are located behind a discreet side panel. Improved back-focus setup mechanism provides easy camera installation.

The new Siemens 1.3 megapixel box camera range is a true CCTV IP security camera range that combines the requirements of classic analogue CCTV cameras with the high performance, flexibility and IT security of a modern video-over-IP device. For easy video setup, the camera supports a classic CVBS video output that can be activated via an internal switch. Thus even a later migration from classic video to IP video can be achieved without change of the camera model.

Features like activity (motion) detection, PTZ device control via RS485 output, privacy zones, the integrated firewall with IP filtering, up to 2 GB SD alarm image memory and email notification turn this IP camera into a true video security device.

The CCAS1425-LPO / MPO is a high resolution (480 / 530 TVL) day-night camera with built-in auto focus zoom lens with maximum 242x zoom. The camera is designed for outdoor use under variable lighting conditions. It is built into a compact and attractively styled weatherproof housing with sunshade incorporated. As a result of the day-night function, the camera offers optimum picture quality both under varying daylight conditions and also when used at night with IR light.

All the camera settings such as white balance, exposure settings, setting of back-light compensation (BLC), line-lock synchronisation or digital noise reduction are done via the OSD menu. Each camera can have an individual camera text assigned to it. It is possible to specify via the display menu which text and which detailed information for the setting of the camera is to be displayed in the video image.
