This IP camera offers a compression standard that is inter-changeable between the MJPEG and MPEG4, which ensures highest flexibility and allows a system to be optimised depending upon image quality or bandwidth.

Used in-, outdoor, day or night, the high performance CCD sensor enables very high light sensitivity to deliver outstanding images and as the camera supports MPEG4 as well as the international standard RTSP (Real Time Streaming Protocol), video streams can be replayed using standard PC video players such as, Quick Time or VLC. This ensures that the camera can be easily integrated into both new and existing applications.

Siemens hybrid technology also means that the camera can be transferred from a standard BNC connection present in traditional CCTV systems to a digital format (i.e. swapped from coaxial to Ethernet transmission) in order to remain future-proof.

CCWC1345 is a 500 TVL high resolution colour camera using the latest CMOS Image sensor and 32 bit DPS (Digital Pixel System, PIXIM D2500 *) techniques to provide crisp, aperture corrected images for surveillance applications requiring detailed images even under extreme difficult illumination conditions.

High Resolution Wide Dynamic
The latest 32 bit DPS (Digital Pixel System*) technology enables the ultra wide dynamic video range up to 120 dB, providing video-pictures without over- or underexposed areas.

Twisted Pair video Output
Besides the conventional BNC video output, the integrated twisted pair video output enables the transmission of the video signal via simple twisted pair cabling such as telephone cable over a distance of up to 1200 m using a twisted pair receiver unit such as TP-RXMOD2 or equivalent.

CCWC1335 is a high resolution DSP day-night camera with extended 128x dynamic range. Using the latest CCD technology and advanced SONY SS2-DSP signal processing techniques to provide crisp, aperture corrected images, the CCWC1335 camera can be used in a wide variety of applications where image quality is paramount.

Day-Night with Extended Dynamic Range
The camera can compensate for back-light pictures that have areas with differing levels of light using extended dynamic function. With this feature, both under and overexposed picture segments can be optimally displayed. The switch-over from colour to B&W can be performed automatically depending on ambient light conditions or by external signal using the switch-input of the camera.

Easy Setup
All camera adjustments are performed via a simple to use OSD. Navigation buttons are located behind a discrete side panel. Improved back-focus setup mechanism and function provide easy camera-installation without additional tools such as day-night filters.

Privacy Zones
The camera supports 8 programmable privacy–zones that mask out sensitive picture contents. The masked areas will be displayed blackened.

Datasheet (0.5 MB)
Quick Start Guide (0.7 MB)
User Manual (0.6 MB)
Brochure (2.8 MB)

High-resolution 1/2” colour camera with advanced features including
49-zone programmable back-light compensation, wide dynamic,
peak-white inversion and adjustable electronic shutter, ensuring the best images all of the time. The camera includes a built-in ID system for addressing (via RS485 or TTL) and setup is via on-screen display menu, or via remote setup software. An alarm input triggers up to 4 digital images, stored in the camera and accessible remotely. Supplied with operation and parameterisation software.

High resolution day-night camera with infra red sensitivity, advanced digital signal processing techniques to provide crisp, high resolution, aperture corrected, low-smear images, 24-hours a day. Advanced features include: 49-zone programmable back-light compensation, wide dynamic,
peak-white inversion and adjustable electronic shutter, ensuring the best images all of the time. The camera includes a built-in ID system for addressing (via RS485) and setup is via on-screen display menu, or via remote setup software. An alarm input triggers up to 4 digital images, stored in the camera and accessible remotely. Supplied with setup software.

High-resolution 1/2” monochrome camera including all features of the newest camera and chip technology with improved infra red sensitivity. Advanced features include 49-zone programmable back-light compensation, wide dynamic, peak-white inversion and adjustable electronic shutter, ensuring the best images all of the time. The camera includes a built-in ID system for addressing (via RS485 or TTL) and setup is via on-screen display menu, or via remote setup software. An alarm input triggers up to 4 digital images, stored in the camera and accessible remotely. Supplied with operation and parameterisation software.
